Engine Technology

Proven / reliable, fuel efficient Mitsubishi Tier III D04FD-TAA engine.

Electronically controlled for optimum fuel to air ratio and clean, efficient combustion.

Low noise / Auto engine overheat feature / Anti-restart feature.

Hydraulic System Improvements

New patented hydraulic control for improved controllability / Improved control valve design for added efficiency and smoother operation / New auto boom and swing priority system for optimum speed / New auto power boost feature for additional power when needed / Improved arm-in and boom-down flow regeneration system for added speed and efficiency.

Pump Compartment

Industry-leading, powerful, reliable Kawasaki designed, variable volume in-line axial piston pumps.

New compact solenoid block equipped with 3 solenoid valves, 1 EPPR valve, 1 check valve accumulator and line filter controls.

2 speed travel, power boost, boom priority, arm-in regeneration, safety lock.

Enhanced Operator Cab

• Improved Visibility

Enlarged cab with improved visibility / See-through upper skylight for visibility and ventilation.

Larger right-side glass - now one piece, for better right visibility.

Safety glass windows on all sides - less expensive than (polycarbonate) and won’t scratch or fade.

Closeable sunshade for operator convenience / Reduced front window seam for improved operator view.

• Improved Cab Construction

New steel tube construction for added operator safety, protection and durability.

New window open/close mechanism designed with cable and spring lift assist and single latch release.

• Improved Suspension Seat / Console Assembly

Ergonomic joysticks with auxiliary control buttons for attachment use. Now with new sleek styling.

Adjustable heated suspension seat, control console and arm rests.

• Advanced 7” Color Cluster

New Color LCD Display with easy-to-read digital gauges for hydraulic oil temperature, water temperature, and fuel. A simplified design makes adjustment and diagnostics easier. Also, new enhanced features such as rear-view camera are integrated into monitor.

3 power modes : (P) Power, (S) Standard, (E) Economy, 2 work modes : Dig & Attachment, (U) User mode for operator preference.

Enhanced self-diagnostic features with GPS download capability.

One pump flow or two pump flow for optional attachment now selectable through the cluster / New anti-theft system with password capability.

Boom speed and arm regeneration are selectable through the monitor.

Auto power boost is now available - selectable (on/off) through the monitor.

Powerful air conditioning and heat with auto climate control, 20% more heat and air output than 7A series!

RMS (Remote Management System) works through GPS/satellite technology to ultimately provide better customer service and support.

Undercarriage

Sealed track chain (urethane seals) / Standard track rail guard / Comfortable bolt-on steps Large upper roller cut-outs for debris clean-out / Tapered side frames for debris clean-out / Grease-type track tensioner
